Single Acting Hollow Plunger Hydraulic Cylinders
Home /
Hydraulic Cylinders /
Single Acting Hollow Plunger Hydraulic Cylinders
Single Acting Hollow Plunger Hydraulic Cylinder 10 Ton 50mm Stroke RCH-1050 BARTON
Description
Request
Informasi Pemesanan
Untuk order ini silahkan isi form dibawah ini
Team marketing kami akan segera menghubungi anda dan memberikan anda solusi dan harga terbaik untuk keperluan anda.
Name
Email
Telephone
Message
Keluar
Company URLs
Download Catalogue
Manual
Video
Tweet
Specifications
With Saddle (Anti Slip)
Suitable for Vertical, Horizontal, Upside Down Positions
Model
RCH-1050
Pump System
Single Acting 700 Bar / 10000 psi
Cylinder Capacity @700 Bar
10 Ton
Body Height
130 mm (No Saddle) / 130 mm (With Saddle)
Travel / Stroke
50 mm
Total Height
180 mm (No Saddle) / 180 mm (With Saddle)
Oil Capacity
85 ml
Piston Diameter
42 mm
Hole Diameter
20 mm
Outside Diameter
75 mm
Effective Area
15.9 cm²
Saddle
Yes, Diameter 42 mm
Dust Seal
No
Handle
No
Connection
Male 3/8" NPT x Male Coupler ZG
Mounting
Base Mounting Hole
Inner Piston Thread
Package Includes
Cylinder RCH-1050 x1
Manual Instruction x1
Quality Certificate x1
Unit Weight
3.56 kg
Packing Weight
6 kg
Packing Dimension
160x160x200 mm
